Cerebral Autosomal Dominant Arteriopathy with Subcortical Infarcts and Leukoencephalopathy (CADASIL)

Headaches and confusion in 55F • Xray of the Week 2016 • Week #3

This 55 year old Hispanic female with past medical history of type 2 diabetes, hypertension, and hyperlipidemia, presented with 3 days of headaches and confusion. An MRI brain was performed, and due to the findings, genetic testing was performed. A mutation on chromosome 19q12 involving the Notch 3 gene was discovered. What is the diagnosis?

Figure 1. CADASIL A: MRI- FLAIR axial image shows symmetric T2 hyperintensities in the anterior temporal lobes. B: MRI- DWI axial image shows no acute infarct.

Figure 2. CADASIL Patient #2 A: MRI- FLAIR axial image shows symmetric T2 hyperintensities in the anterior temporal lobes in patient #2. B: MRI- FLAIR axial image shows confluent symmetric white matter T2 hyperintensity changes in patient #2.

Cerebral Autosomal Dominant Arteriopathy with Subcortical Infarcts and Leukoencephalopathy (CADASIL) is an autosomal dominant condition which has an onset of symptoms between ages 30 to 50. [1,2] The gene mutation causes small vessel and arteriole stenosis as a result of fibrotic thickening of the basement membrane of the vessels. Symptoms are non-specific but may include weakness, dementia, focal neurological defects, and seizures due to recurrent transient ischemic attacks (TIA's). [1,2,3] On MRI, the anterior temporal lobes are affected up to 86% of the time [Fig. 1] and the external capsule is affected in up to 93% of cases at presentation. There are often confluent white matter regions of increased signal intensity on T2 weighted images, with a predilection for the anterior temporal lobe [Fig 2]. More circumscribed lesions may also be visualized in the basal ganglia, thalamus and pons; however, there is usually sparing of the cortex and subcortical U-fibers. [1,2] Treatment is supportive, and prognosis is poor as symptomatology is progressive. [1,3]

References:

1. Yousry TA, Seelos K, Mayer M et-al. Characteristic MR lesion pattern and correlation of T1 and T2 lesion volume with neurologic and neuropsychological findings in cerebral autosomal dominant arteriopathy with subcortical infarcts and leukoencephalopathy (CADASIL). AJNR Am J Neuroradiol. 1999;20 (1): 91-100.

2. Auer DP, Pütz B, Gössl C et-al. Differential lesion patterns in CADASIL and sporadic subcortical arteriosclerotic encephalopathy: MR imaging study with statistical parametric group comparison. Radiology. 2001;218 (2): 443-51.

3. Bohlega S, Al Shubili A, Edris A et-al. CADASIL in Arabs: clinical and genetic findings. BMC Med. Genet. 2007;8 : 67.

4. Lotz PR, Ballinger WE, Quisling RG. Subcortical arteriosclerotic encephalopathy: CT spectrum and pathologic correlation. AJR Am J Roentgenol. 1986;147 (6): 1209-14.
